Description

FIRE ALARM CONTROL PANEL is a miniature fire protection system that receives wireless devices. Simple human-machine interface and easy operation. A wireless module with long-distance, anti-interference, and strong stability can receive information from each wireless firefighting equipment. Equipped with dual power supply of mains and lithium batteries, automatic switching.

Features
1. A wireless module with long-distance anti-interference and strong stability, can receive information from each wireless firefighting equipment.
2. Equipped with dual power supply of mains and lithium batteries. If main power fail to supply power, it will switch to lithium battery for keeping power supply.
3. A panel can receive up to 99 wireless fire protection device messages and can remotely send alarm messages to the user's mobile phone through SIM.
4. Multiple non-interfering panels can be installed in the same location to receive wireless firefighting equipment.

Technical Specification

Model	AW-FP032
Rated input voltage	85V-265VAC，50Hz/60Hz
Standby battery capacity	2000mAh 3.7V/ lithium battery
Working environment	Relative humidity (<95%) at -20 ~40 ℃, no condensation)
Number of connected devices	99PCS
The number of mobile phones that can be sent to text	10
Alarm Horn	≥100dB@1m
Flashing frequency	1Hz
Wireless Working Frequency	433MHz （418MHz-448MHz）
Size	240mm160mm51mm
